FLUXMIG-120 Flux Core Gasless/Lift TIG/Stick 3-in-1 MIG Welder(EU PLUG / 220V)

FLUXMIG-120 Flux Core Gasless/Lift TIG/Stick 3-in-1 MIG Welder(EU PLUG / 220V)

Regular price $111.87 USD
Regular price Sale price $111.87 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
PACK

FLUXMIG series multi-process welding machines are the ideal choice for DIY and Outdoor site welding. The compact and lightweight design is easy to carry. Machine dedicated to airless MIG welding, also with MMA and LIFT DC TIG functions.

Multifunctional:LEVIN FLUXMIG is a portable inverter-based MCU controlled semi-bridge welding machine that combines a MIG gas-free MMA and a TIG Lift DC.All functions are easily displayed on the screen. Note: Aluminum cannot be welded
Easy to use: The screen will give the recommended thickness of the solder while adjusting the current! Easy to use, MIG support using mm0.8 as well as 1 mm solder wire welded core without gas, wire ready to use. Simultaneously in MMA mode, it supports manual adjustment of hot start and arc force functions to help better priming
Easy to carry: The weight of the machine is 5kg, the body is small and light, very convenient to carry. The maximum power of the machine is 3.7 kW (maximum current of 120 A), making it ideal for home and DIY use.

View full details

Collapsible content

Package Include

PACKAGE INCLUDE:

  • FLUXMIG-140 machine *1
  • 300A Grounding Clamp(wire 2 meters / 6.56ft)
  • 200A Electrode Holder(wire 2 meters / 6.56ft)
  • 14AK MIG Torch(2 meters / 6.56ft)
  • K type Roller 0.8/1.0mm(installed)
  • K type Roller 0.6/0.8mm
  • 0.45KG Flux cored wire(0.8mm)

Specifications and Parameters

  • Model: FLUXMIG-140
  • FUNCTION: NO GAS MIG(Flux wire. 0.8/1.0mm) / LIFT TIG / MMA
  • Input Voltage: 220V
  • Current output Max: MIG=140A / TIG=120A / MMA=140A
  • No-load voltage:56V
  • Sun Function(MMA): Arc Force / Hot Start
  • Machine weight: 4.7KG
  • Package weight:8KG
  • Duty Cycle:

MMA : 20%@140A / 60%@110A / 100%@85A

MIG : 25%@140A / 60%@120A / 100%@100A

TIG : 40%@140A / 60%@120A / 100%@110A

WELDER TESTING
